MC 296 35D

MC-296-35DMC-296-35D

 MC-296-35D

Standards
IEC 61230
LV earthing equiment

Use :

  • Earthing and short-circuiting equipment for low voltage cabinets or industrial installations.
  • Icc : 8 kA/1s.

Characteristics :

  • Complete set with accessories adapted to different installations configurations.
  • Delivered in plastic carrying case.

Composition :

  • 1 earthing and short-circuiting assembly with 4 branches made of copper cable with silicon insulation, cross-section 25 mm².
  • 2 earthing and short-circuiting assembly with 4 branches made of copper cable with silicon insulation, cross-section 35 mm².
  • 2 earth clamps on flexible handle MC296PD.
  • 3 insulated fuses size  00 MC2960008.
  • 6 insulated fuses size 115 MC29611508.
  • 2 cylindrical connection points 63614.
  • 2 cylindrical connection points Threaded 63657.
  • 1 insulated wrench at 4 dimensions : 13, 14, 16, 17 mm MO687D
  • 1 insulating handle MC296M.
  • 1 plastic carrying case.

Data Sheet



Reference Dimensions (mm) Weight (kg)
MC-296-35D 500 x 350 x 120 6
